class: center, middle, inverse, title-slide # Deploying TensorFlow Models ## with tfdeploy ### <a href="https://github.com/javierluraschi">Javier Luraschi</a> ### February 2018 --- class: rstudio-slide, left, rstudio-overview # Overview - **Train** and **Export** models with [tensorflow.rstudio.com](https://tensorflow.rstudio.com) - **Test** deployments with [tfdeploy](https://github.com/rstudio/tfdeploy). - **Deploy** with [cloudml](https://github.com/rstudio/cloudml) and [rsconnect](https://github.com/rstudio/rsconnect). - **Predict** models from any platform!  --- class: rstudio-slide, left # Train **Train** models with [tensorflow.rstudio.com](https://tensorflow.rstudio.com)  --- class: rstudio-slide, left, tfdeploy-code-image # Export Use `export_savedmodel()` across Keras, Estimators and the Core API. .pull-left[ ```r # Keras API export_savedmodel(model, "mnist") # Estimator API export_savedmodel(model, "mtcars") # Core API input <- list(images = x), output <- list(scores = y) export_savedmodel(sess, "mnist", input, output) ``` ] .pull-right[  ] --- class: rstudio-slide, left, tfdeploy-code-image # Test - Install `tfdeploy` from [github.com/rstudio/tfdeploy](https://github.com/rstudio/tfdeploy) - Run `serve_savedmodel()` to serve and test your model: .pull-left[ ```r # Install tfdeploy from GitHub devtools::install_github("rstudio/tfdeploy") # Run local server with model serve_savedmodel("<model-name>") ``` ] .pull-right[  ] --- class: rstudio-slide, left, tfdeploy-code-image # Deploy Deploy models to [TensorFlow Serving](https://github.com/tensorflow/serving), [CloudML](https://tensorflow.rstudio.com/tools/cloudml/articles/getting_started.html) or [RStudio Connect](https://www.rstudio.com/products/connect/). .pull-left[ ```r # Deploy to CloudML library(cloudml) cloudml_deploy("keras-mnist", "rstudio-conf") ``` ```r # Deploy to RStudio Connect library(rsconnect) deployTFModel("keras-mnist") ``` ] .pull-right[  ] --- class: rstudio-slide, left # Predict Predict using **any programming language**. ```bash curl -d @examples/digit-zero.json http://localhost:3939/content/2/predict ``` .thin-block[   ] --- class: rstudio-slide, left # Thanks! - Slides: [rpubs.com/jluraschi/](https://rpubs.com/jluraschi/) - R Notebook: [Slides](https://s3.amazonaws.com/javierluraschi/tensorflow-deployment-rstudio-conf/deploy-tensorflow-models-with-tfdeploy.Rmd) - [Demo](https://s3.amazonaws.com/javierluraschi/tensorflow-deployment-rstudio-conf/deploy-tensorflow-models-walkthrough.Rmd) --- class: rstudio-slide, left, tfdeploy-code-image # Predicting from JavaScript? TensorFlow predictions in JavaScript with [kerasjs](https://gist.github.com/rstudio/kerasjs): .pull-left[ ```r # Install kerasjs from GitHub devtools::install_github("rstudio/kerasjs") # Train and Export model from Keras as HDF5 # or use an existing model model_path <- system.file( "models/keras-mnist.hdf5", package = "kerasjs" ) # Convert model to JavaScript and Preview kerasjs_convert(model_path) ``` ] .pull-right[ .mnist-digits[ ] ] --- class: rstudio-slide, left, tfdeploy-code-image # Predicting from Shiny? Using `shiny` to perform a prediction over a load or deployed TensorFlow model: .pull-left[ ```r data <- list(instances = list( list(pixels::get_pixels()) )) # Request prediction from deployed model httr::POST(url, body = toJSON(data)) # Or directly from TensorFlow tfdeploy::predict_savedmodel(data) # Then assign to reactive, etc. ``` ] .pull-right[  ] --- class: rstudio-slide, left, tfdeploy-code-image # Predicting from Spark? [TensorFlow predictions in Spark with sparklyr](https://gist.github.com/javierluraschi/aaf0ef91fcd9e368478bae7e4c883e85): .pull-left[ ```r mtcars_tbl %>% spark_apply(function(df) { instances <- unname(apply(df, 1, function(e) list(cyl = e[2], disp = e[3]) )) results <- tfdeploy::predict_savedmodel( instances, "tfestimators-mtcars.tar", signature_name = "predict" ) unname(unlist(results)) }) ``` ] .pull-right[  ]
